Bộ chuyển mạch đồng trục đa cổng KEYSIGHT 87104C (DC to 26.5 GHz, SP4T Terminated)
Product Details
Manufacturer:
KEYSIGHT
Model:
87104C
Warranty:
Origin:
-
Technical Specifications
- Frequency range: DC to 26.5 GHz
- Specifications
- Life: 5,000,000 cycles minimum
- Switching speed: 15 ms maximum
- Indicator specifications
- Maximum withstand voltage: 60 V
- Maximum current capacity: 150 mA
- Maximum “ON” resistance: 2.5 Ω
- Maximum “OFF” resistance: 10 G Ω
- Maximum power rating
- Into internal termination: 1 W CW50 W peak, 10 µs max pulse width, not to exceed 1 W average
- Into thru path Hot switching: 2 W CW100 W peak, 10 µs max pulse width, not to exceed 2 W average
- Environmental specifications
- Operating temperature: –25 to 75 °C
- Storage temperature: –55 to 85 °C
- RFI: Per MIL-STD-461C, RE02, Part 4
- Magnetic field: <
