Công tắc hành trình Omron Z4W-V25R 5M

Technical Specifications

• Measurement range ±4 mm
• Measurement point 25±1 mm
• Light source Red LED
• Spot diameter 2-mm dia. (at measurement point)
• Resolution 10 microns (See Note. 1)
• Linearity ±3% FS (See Note. 2)
• Response time 5 ms (In case of white alumina ceramic. Linearity change according to object.)
• Temperature characteristics ±0.3% FS/°C
• Warming up time 3 min (within 1% of stable value)
• Indicators
  •  Stability:
    • Stable range: Lit green
    • Operating range: Not lit
    • Dark: Lit red
  • Range:
    • In range: Green
    • Out of range: Red
• Outputs
  • Analog output:
    • 4 to 20 mA/±4 mm
    • Load impedance: 300Ω max.
  • DARK output:
    • NPN open collector
    • 50 mA max., 30 VDC
    • Residual voltage: 1 V max.
• External light 3,000 ln (incandescent light)
• Power supply voltage 12 to 24 VDC±10%: ripple (p-p) 10% max.
• Current consumption 80 mA max.
• Vibration resistance Destruction: 10 to 55 Hz (1.5-mm double amplitude) for 2 sweeps of 15 min each in X, Y, and Z directions
• Shock resistance Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions
• Ambient temperature Operating: -10° to 55°C (with no icing)
• Ambient humidity 35% to 85% (with no icing)
• Degree of protection IP66
• Weight 150 g (with 5-m cable); 50 g (without cable)
• Attachments Mounting bracket, mounting screws, resistor (250Ω, 0.5 W)
