Bộ nguồn DC 2 đầu ra với 2 dải tùy chọn KEYSIGHT E3646A (0-8V/3A & 0-20V/1.5A, 60W)

Technical Specifications

• Maximum power: 60 W
• Number of outputs: 2
• Output ratings (0°C to 40°C)
  • Range 1: 0 to 8V/3A
  • Range 2: 0 to 20V/1.5A
• Programming accuracy (@25°C±5°C):
  • Voltage: <0.05% + 10 mV
  • Current: <0.2% + 10 mA
• Ripple & noise 20 Hz to 20 MHz
  • Normal Mode Voltage: <5 mVpp / 0.5 mVrms
  • Normal Mode Current: <4 mArms
• Load and line regulation:
  • Voltage < 0.01% + 3 mV
  • Current < 0.01% + 250 μA
• Resolution:
  • Program < 5 mV/1 mA
  • Readback < 2 mV/1 mA
  • Meter 10 mV/1 mA
  • Settling time 3 < 90 ms
• Power cord: AC 100- 230 V, 47- 63 Hz
• Interface: GPIB and RS232
