Product Details
Manufacturer:
EXTECH
Model:
MS460
Warranty:
Origin:
-
Technical Specifications
- Oscilloscope Functions
- Display Size: 3.8" (96mm) color LCD; 320 x 240 pixels
- Bandwidth: 60MHz
- Real time: sample rate 250MS/s
- Risetime: 17.5ns
- Channels: 2
- Record Length: 6K points per channel
- Glitch Capture: 50ns
- Vertical Sensitivity: 5mV to 5V/div
- Vertical Resolution: 8 bits
- Timebase Range: 5ns to 5s/div
- Sample Mode: Sample, Average, Peak Detect
- Trigger Modes: Free Run, Single Shot, Edge, Video
- Trigger Source: CH1, CH2
- Trigger Coupling: AC, DC
- Input impedance: 1MΩ/20pF
- Max Input Voltage: 400V (peak)
- Cursor Measurement Voltage: and time; Delta (CH1-CH2)
- True RMS MultiMeter Functions
- AC/DC Voltage: 400mV, 4V, 40V, 400V
- AC/DC Current: 40mA, 300mA, 20A
- Resistance: 400Ω, 4kΩ, 40kΩ, 400kΩ, 40MΩ
- Capacitance: 51.2nF to 100μF
- Diode and Continuity: Yes
- PC Interface USB cable
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
Customs Description
Máy hiện sóng cầm tay Extech MS460 (60MHz, 2-Channel)
