Technical Specifications

• 1. Measurement range :
  • pH: (-2.00~18.00)pH
  • mV: (-1999.9~1999.9)mV
  • Temp.: (0..0~100.0) °C
• 2. Resolution:
  • pH:0.01pH,
  •  mV: 1 mV
  • Temp.: 0.1°C
• 3. Accuracy
  • pH: ±0.01pH±ibit
  • mV: ±1mV±1bit
  • Temp.: ±0.3 °C±1bit
• 4. Input impedance:1 x 1012 Ω
• 5. Stability: ±0.01pH ±1bit/3h
• 6. Temperature compensation range: 0.0~100.0°C
• 7. The temperature of the measured solution:5~60°C
• Standard Configuration:
• 1.    Main instrument                         1;
• 2.    Power cable                              1;
• 3.    PH Combined Electrode            1;
• 4.    Temperature Sensor                  1;
• 5.    Multi-function Electrode Support Stand      1;
• 6.    PH4.00, 6.86, 9.18 Buffer           5 bags for each;
• 7.    Data Collecting Software              1;
• 8.    RS-232 Communication Line        1;
• 9.    TP-16 Print Connection Line         1.
• Overall dimension & weight:
• Shipping package dimension: 332*265*275mm;
• Gross weight:              3kgs;
• Net Weight:                2kgs.
